JASCO - VIR-100/200/300 Series
Manufactured by JASCO
Portable FTIR Systems - VIR-100/200/300 Series
The VIR-100/200/300 series are compact, lightweight, flexible FT-IR systems. The collimated entrance and exit ports make it an ideal instrument for a wide range of applications. The standard instrument includes a hermetically sealed interferometer, DLATGS detector, high intensity source, KRS-5 windows and automatic alignment. Options can be added for increased sensitivity, optional spectral ranges including NIR, and battery operation.
Active Questions & AnswersAsk a Question
There are no current Discussions
Need Equipment Support?
Documents & ManualsView All Documents
Features of VIR-100/200/300 Series
- Three models available: VIR-100, 200 and 300.
- Simple and easy-to-use operability by combination of a variety of attachments and measurement/analysis program
- Parallel configuration of up to three attachments in one system by newly developed
- External connection optics
- Universal optical base allowing the users to build customized systems
- Eco-friendly system including sleep-mode as well as compact & space-saving design
- High-speed monitoring using optional 40 Hz rapid scan
- Highly reliable data acquisition based on self-diagnostics & validation function
General Specifications
There are no General Specifications available.
Series Modals
JASCO - VIR-100
[+] View Model Specifications| Signal-to-Noise Ratio | 12000:1 |
| Wavenumber Range | 7000 to 400 cm-1 |
| Additional Model Specifications | Resolution: 4 ~ 16 cm-1 |
JASCO - VIR-200
[+] View Model Specifications| Signal-to-Noise Ratio | 15000:1 |
| Wavenumber Range | 7800 to 350 cm-1 |
| Additional Model Specifications | Resolution: 0.5 ~ 16 cm-1 |
JASCO - VIR-300
[+] View Model Specifications| Signal-to-Noise Ratio | 3000:1 |
| Wavenumber Range | 15000 to 2200 cm-1 |
| Additional Model Specifications | Resolution: 0.5 ~ 16 cm-1 |
