Malvern Panalytical - Aero S
Manufactured by Malvern Panalytical
No Documents
State-of-the-art dry powder dispersion
Setting new standards for dry powder dispersion, the Aero S has been designed from the ground up based upon fundamental powder dispersion theory. The modular design ensures rapid and reproducible dispersion of the widest range of samples from cohesive powders to fragile materials.
The Aero S is a completely new dry powder disperser developed using state-of-the-art powder dispersion understanding. Modular in design, it is easily configured for different applications, delivering efficient sample dispersion for both robust and fragile materials.
The Aero S is a completely new dry powder disperser developed using state-of-the-art powder dispersion understanding. Modular in design, it is easily configured for different applications, delivering efficient sample dispersion for both robust and fragile materials.
Active Questions & AnswersAsk a Question
There are no current Discussions
Particle Size Analyzers Service ProvidersView All (2)
Documents & Manuals
There are no Documents or Manuals available.
Features of Aero S
- Standard disperser suitable for both cohesive and fragile particle measurements.
- Impaction systems available for robust material dispersion.
- Precise dispersion pressure control, to ±0.1 bar delivers outstanding reproducibility.
- Range of sample feed trays and hoppers enable measurement of different sample volumes.
- Enclosed cell delivers bias-free measurements whilst minimizing user exposure to the sample.
- Full software control of all measurement functions, including sample feed and dispersion.
- Ceramic dispersers available for abrasive materials.
General Specifications
| Depth | 260 mm |
| Height | 380 mm |
| Width | 180 mm |
| Weight | 10.5 kg |
Additional Specifications
Particle size: 0.1 - 3500 µm †
Dispersion pressure range: 0 - 4 bar
Pressure setting precision: +/- 0.1 bar
Pressure setting accuracy: +/- 0.03 bar
Feed rate range: 0 - 58ms-2 (expressed as 0-100%)
Feed rate precision: 2% FS
Materials in contact with the dispersant, additives and sample: 316 stainless. 410 hardened stainless. Borosilicate glass. EPDM. PTFE. Polyurethane. Carbon filled acetal. Aluminum. Neoprene.
Maximum particle size: 3500 µm †
Minimum time between measurements: Less than 60 seconds †
