Deltech - Horizontal Tube Furnaces
Manufactured by Deltech
No Documents
Deltech manufactures furnaces for use in inert atmospheres and up to 5% hydrogen mixtures. Models include vertical tube, horizontal tube, split...
Deltech manufactures furnaces for use in inert atmospheres and up to 5% hydrogen mixtures. Models include vertical tube, horizontal tube, split shell, bottom loading vertical tube, and atmosphere envelopes with operating temperatures up to 2000° C depending upon the model chosen and particular gases to be used.
Active Questions & AnswersAsk a Question
There are no current Discussions
Lab Furnaces Service ProvidersView All (8)
Documents & Manuals
There are no Documents or Manuals available.
Features
There are no Features available.
General Specifications
There are no General Specifications available.
Series Modals
Deltech - DT-29-HT-11(1600 DEG C)
[+] View Model Specifications| Power Requirements | 10 kW |
| Weight | 225 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 11″ / 28cm Furnace Dimensions 25″x 22″ x 34 ” / 64cm x 56cm x 86cm |
Deltech - DT-29-HT-17(1600 DEG C)
[+] View Model Specifications| Power Requirements | 12.5 kW |
| Weight | 350 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 17″ / 43cm Furnace Dimensions 34 “x 22″ x 44” / 86cm x 56cm x 112cm |
Deltech - DT-29-HT-30(1600 DEG C)
[+] View Model Specifications| Weight | 436 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 30″ / 76cm Furnace Dimensions 48″ x 22″ x 47″ / 121cm x 56cm x 120cm Power Requirements 20 kW |
Deltech - DT-29-HT-36(1600 DEG C)
[+] View Model Specifications| Weight | 478 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 36″ / 91cm Furnace Dimensions 54″ x 22 ” x 47″ / 137cm x 56cm x 120cm Power Requirements 22.5 kW |
Deltech - DT-29-HT-7 (1600 DEG C)
[+] View Model Specifications| Power Requirements | 3 kW |
| Weight | 150 lbs |
| Additional Model Specifications | Tube O.D.
Less than 3.25″ / 83mm Hot Zone Length 7″ / 18cm Furnace Dimensions 18″ x15″ x 30″ / 46cm x 38cm x 76cm |
Deltech - DT-31-HT-11 (1700 DEG C)
[+] View Model Specifications| Weight | 225 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 11″ / 28cm Furnace Dimensions 25″x 22″ x 34 ” / 64cm x 56cm x 86cm Power Requirements 10 kW |
Deltech - DT-31-HT-17 (1700 DEG C)
[+] View Model Specifications| Weight | 350 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 17″ / 43cm Furnace Dimensions 34 “x 22″ x 44” / 86cm x 56cm x 112cm Power Requirements 12.5 kW |
Deltech - DT-31-HT-24 (1700 DEG C)
[+] View Model Specifications| Weight | 385 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 24″ / 61cm Furnace Dimensions 42″ x 22″ x 47″ / 107cm x 56cm x 120cm Power Requirements 15 kW |
Deltech - DT-31-HT-36 (1700 DEG C)
[+] View Model Specifications| Weight | 478 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 36″ / 91cm Furnace Dimensions 54″ x 22 ” x 47″ / 137cm x 56cm x 120cm Power Requirements 22.5 kW |
Deltech - DT-31-HT-7 (1700 DEG C)
[+] View Model Specifications| Weight | 150 lbs |
| Additional Model Specifications | Tube O.D.
Less than 3.25″ / 83mm Hot Zone Length 7″ / 18cm Furnace Dimensions 18″ x15″ x 30″ / 46cm x 38cm x 76cm Power Requirements 3 kW |
Deltech - DT-33-HT-11 (1800 DEG C)
[+] View Model Specifications| Weight | 225 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 11″ / 28cm Furnace Dimensions 25″x 22″ x 34 ” / 64cm x 56cm x 86cm Power Requirements 15 kW |
Deltech - DT-33-HT-17 (1800 DEG C)
[+] View Model Specifications| Weight | 350 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 17″ / 43cm Furnace Dimensions 34 “x 22″ x 44” / 86cm x 56cm x 112cm Power Requirements 15 kW |
Deltech - DT-33-HT-24 (1800 DEG C)
[+] View Model Specifications| Weight | 385 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 24″ / 61cm Furnace Dimensions 42″ x 22″ x 47″ / 107cm x 56cm x 120cm Power Requirements 15 kW |
Deltech - DT-33-HT-30 (1800 DEG C)
[+] View Model Specifications| Weight | 436 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 30″ / 76cm Furnace Dimensions 48″ x 22″ x 47″ / 121cm x 56cm x 120cm Power Requirements 20 kW |
Deltech - DT-33-HT-36 (1800 DEG C)
[+] View Model Specifications| Power Requirements | 22.5 kW |
| Weight | 478 lbs |
| Additional Model Specifications | Tube O.D.
Less than 5″ / 127mm Hot Zone Length 36″ / 91cm Furnace Dimensions 54″ x 22 ” x 47″ / 137cm x 56cm x 120cm |
Deltech - DT-33-HT-7 (1800 DEG C)
[+] View Model Specifications| Weight | 150 lbs |
| Additional Model Specifications | Tube O.D.
Less than 3.25″ / 83mm Hot Zone Length 7″ / 18cm Furnace Dimensions 18″ x15″ x 30″ / 46cm x 38cm x 76cm Power Requirements 7.5 kW |
