Available in 1 and 2 Person Sizes (182 cm and 91 cm). 24" depth (61 cm) and 36" height (91 cm)


• All construction is from the following durable materials:
• Epoxy-coated aluminum (1/8", 3.2mm thick),
• Clear polycarbonate (1/4", 6.4mm thick),
• Optically clear flexible PVC, polyvinyl chloride,   (20-30 mils, 0.5-0.8mm thick)
• EPOM rubber gaskets
• Advanced silicone adhesives and sealants
• Leakproof self sealing fasteners.

   To maximize interior work area and ease of maintenance, many accessories are mounted to the exterior of the glove box.      Quick disconnect fittings have been used wherever possible.      Many of the accessories can be used together to simultaneously control multiple aspects of the glove box environment, such as humidityand oxygen control, or temperature and humidity.      The viewing screen is designed to provide good interior shadow-free ambient light. Tempered Glass may be substituted for the standard polycarbonate for certain chemical operations.      All units are hermitically sealed and pressure checked at the factory for leaks. An inexpensive gas leak detector can be purchased for field testing.      GFI power lines are installed in humidified systems.      A Pressure Relief Valve and Ball Valve are installed on all units to provide a simple Flow thru gas system without over pressurizing the Glove Box. For Isolation Systems the Pressure Relief Valve that vents to room air can be removed or sealed and equiped with tubing for routing to a fume hood or house evacuation system.       Also standard is the Patented Diaphragm Top for easy of operation and cost savings under anaerobic conditions.
