• Dynamic mixing with automatic computation of component and balance gas flow rates allows the user to formulate ppb standards and vary the concentration.
• Minimizes inventory of expensive, long lead time, VOC gas cylinders. Save on gas costs, cylinder rental and handling labor.
• Computerized K-factor correction insures accurate use of all gases based on thermal density.
• Internally-stored mass flow controller calibration data improves accuracy.
• High capacity memory permits storage and recall of up to 200 multi-component "recipes", saving time and reducing errors.
• 25 line by 80 character display permits viewing of data in worksheet form.
• Modular design allows user to add additional gas circuits later, reducing initial investment and protecting against obsolescence.
• Optional RS-232 Serial Data Interface permits remote operation and complete integration with a data station.
• Optional Status board allows user to remotely activate different modes of the system and also activate external devices.

SOFTWARE

The Series 2014 has six primary routines accessible through on screen "soft" keys.

• Concentration Mode: User enters target output gas concentration for the span gas. The actual concentration is displayed during mixing.
• Flow Mode: User enters target flow rate for each component gas. Actual flow rates are displayed after mixing is initiated.
• Maintain Ports: User enters the name of the component gas in the source cylinder, its concentration and the port to which it is connected.
• Divider Mode: Allows the user to operate the instrument as a computerized ten step gas divider.
• Automatic Sequencer: Permits unattended automatic operation of the instrument on a programmable seven-day schedule.
• Purge Mode: Purge component gas circuits and mixing zone.
